Specification Overview
| Maximum Working Height | 7.79m |
| Maximum Platform Height | 5.79m |
| Overall Width | 0.81m |
| Stowed Length | 2.07m |
| Stowed Height | 1.76m |
| Platform Capacity | 230kg/120kg on deck extension |
| Gross Machine Weight | 1565kg |
| Gradeability | 25% |
| Tyres | non-marking solid |
| Overall Length | 2.07m |
| Deck Extension | 0.71m |
| Ground Clearance | 8cm |
To hire this machine, or for more information.
0345 457 0000 Contact formFeatures
- Passive pothole protection eliminates all moving parts in the pothole protection system, reducing the need for repair or replacement
- Ability to traverse grades of up to 25%
- Innovative operator controls, similar to the ES Series, and compact dimensions enable travel through doorways
- The direct electric drive delivers industry-leading duty cycles
- Leak points are minimised with a design that includes 4 hydraulic hoses
- Battery storage areas are easily accessible and have no drawers to pull out
